Frequency range

0.1 to 1000 MHz

Frequency entry

1kHz

Measurement for systems

12.5, 25, 28, 37, 50, 75, 100, 150, 200, 300, 450, 600 Ohm

SWR measurement range

1 to 10 in chart modes, 1 to 100 in numerical modes

R and X range

0… 10000, -10000… 10000

Display modes

HAM (a quick check of single band antenna), Multé (a quick check of multiband antennas), OSL calibration mode, R, X chart, Return loss chart, Single (measure SWR, |Z|, R, , RL, Mag&Phase), SWR chart, TDR (distance to fault), Cable tools (StubTuner, Cable Length, Impedance, Loss measurements)

RF output

Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square

Power

One lithium-ion battery 3.7 V type 18650, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources, Charge time: 3 hours when using a charger

Interface

2 × 3 keys on the waterproof keyboard, 290×220 color TFT display, Menus and help screens in English (by default), Japanese, USB connection to a personal computer

Operating temperature

-20°- 55°C (-4°-131°F)

Weight

185 grams (6.5 Oz) with battery

Dimensions

185 x 40 x 33 mm (7.3 x 1.6 x 1.3 inches)

Accessories inside the box

Quick-start guide, Neck strap, USB cable, N-type to UHF adapter

GTIN-13

4820185420365

Note

Specifications are subject to change without notice, Made in Ukraine
